How to make embossed paper?

GIMP or GIMP LEARN forum related Questions
enxio27
Forum Member

How to make embossed paper?

Post#1 by enxio27 » 09 Feb 2019, 04:04


I want to make embossed "paper" (tone on tone) for digital scrapbooking. I have some patterns to use, and I have played around with the embossing filters and scripts, but I can't seem to get it to work the way I want. I've searched for tutorials, but none of the ones I found are getting me there, either. Any ideas on how to go about this, or maybe a link to a tutorial I missed?
GIMP Learn rocks...

Blighty
Forum Member

Post#2 by Blighty » 09 Feb 2019, 06:50


enxio27 wrote:
09 Feb 2019, 04:04
but I can't seem to get it to work the way I want.
Can you give an example of the effect you are wanting?
GIMP Learn rocks...

enxio27
Forum Member

Post#3 by enxio27 » 09 Feb 2019, 22:16


Here are a few. They don't have to be this fancy, but these were the best images I could find to demonstrate the effect I'm trying to create. I just want to take a pattern (perhaps a herringbone, or a quatrefoil, or a grid) and make it look like the texture was embossed into paper.




GIMP Learn rocks...

tim
GL Blogger

Post#4 by tim » 09 Feb 2019, 22:53


Here are my tries with grid and herringbone.
I just created a solid color layer and use a black & white design as bump map and used a high ambient light factor.
Attachments
embossed_paper_grid_pattern.jpg # (76.19 KiB) Viewed 2685 times (Thumbnail | Recognize | Sq Tile)
embossed_paper_herringbone.jpg # (450.7 KiB) Viewed 2685 times (Thumbnail | Recognize | Sq Tile)
aka Tin



enxio27
Forum Member

Post#5 by enxio27 » 10 Feb 2019, 00:12


tim wrote:
09 Feb 2019, 22:53
Here are my tries with grid and herringbone.
I just created a solid color layer and use a black & white design as bump map and used a high ambient light factor.
That's great! I'm still pretty new to GIMP. Can you tell me the steps you used?
GIMP Learn rocks...

tim
GL Blogger

Post#6 by tim » 10 Feb 2019, 03:37


Okay.
  1. Put your black and white design on a layer.
  2. On another layer (on top) fill it with solid color that you want your paper to have.
  3. Select (make your solid color layer active)
  4. Click on menu item Filters/Map/Bump Map. For Aux Input, click the big question mark to select the black and white layer (to use as bump map). Then you can play with Azimuth and Elevation (optional). I just bumped up Ambient Lighting Factor so that it's not so black and white but subtle. You can see the changes on your images as you play with these settings.
  5. Click OK when you're happy with the settings.
Hope that helps.
aka Tin



oldmangrumpy
Tutorial Creator

Post#7 by oldmangrumpy » 10 Feb 2019, 08:54


Hi Enxio27

In addition to what Tim has provided, the Bump Map filter parameters also provide an option (on 2.8 but I presume 2.10 also) for 'Invert bumpmap'.

I used it with one of my patterns on 'rusted paper' as below -
Attachments
emboss_bump_map.png # (1.59 MiB) Viewed 2660 times (Thumbnail | Recognize | Sq Tile)
Senior's moments are just part of a lifelong learning experience - never stop learning
OMG's: Downunder Art Thread | Gold Ring Addiction

enxio27
Forum Member

Post#8 by enxio27 » 18 Feb 2019, 02:21


These are beautiful, thanks! Unfortunately, I'm going to have to do a little "doctoring" on the design files I have. I thought they were all black and white images, but they're not. I'll be back with some of my attempts once I fix that issue.
GIMP Learn rocks...

Pat625
Tutorial Creator

Post#9 by Pat625 » 19 Feb 2019, 17:18


Here is a tutorial for using Bumpmap in 2.10.


https://gimplearn.net/viewtopic.php/GIM ... 691#p19946
